Oem Health Assessment Equipment Exporter
Health assessment equipment integrates multiple physiological sensors to provide point‑of‑care vitals and biomarker data for occupational health programs. The system is designed for continuous
Inquire NowOEM Health Assessment Equipment Exporter
Health assessment equipment integrates multiple physiological sensors to provide point‑of‑care vitals and biomarker data for occupational health programs. The system is designed for continuous operation in industrial environments, with a sealed enclosure that meets IP65 protection against dust and water jets.
Core Technical Specifications
| Parameter | Specification | Unit | Notes |
|---|---|---|---|
| Heart Rate Range | 30‑240 | bpm | ECG lead‑I, II, III |
| Systolic Blood Pressure | 50‑250 | mmHg | Oscillometric |
| SpO₂ Range | 70‑100 | % | Dual‑wavelength 660/940 nm |
| Temperature Range | 32‑42 | °C | Thermistor, ±0.1 °C |
| Respiratory Rate | 5‑80 | breaths/min | Impedance plethysmography |
| Lactate Detection Limit | 0.2 | mmol/L | Microfluidic electrochemical |
| Average Power Consumption | 8 | W | Li‑ion battery 12 h |
| Operating Temperature | ‑10‑50 | °C | Industrial ambient |
Design and Materials
The enclosure is fabricated from 6063‑T5 aluminum alloy with a medical‑grade polycarbonate overlay, providing a tensile strength of approximately 210 MPa and a surface hardness of 9H. Internal PCBs are conformally coated with acrylic resin to resist corrosion from industrial contaminants. The device weighs 2.3 kg and includes a quick‑release mounting bracket rated for 50 N pull‑force.
Measurement Modalities
- Electrocardiogram (ECG) – 3‑lead, bandwidth 0.05‑150 Hz, resolution 1 µV
- Photoplethysmography (SpO₂) – dual‑wavelength 660 nm/940 nm, sampling rate 100 Hz
- Non‑invasive blood pressure – oscillometric method, measurement interval configurable 10‑300 s
- Skin temperature – thermistor, accuracy ±0.1 °C
- Respiratory rate – impedance plethysmography, frequency range 0.1‑1 Hz
- Biomarker assay – microfluidic cartridge with electrochemical detection, limit of detection 0.2 µmol/L for lactate
Data Integration and Connectivity
The unit provides a USB‑C host port supporting data transfer at 5 Gbps, an Ethernet RJ45 port for 10/100 Mbps LAN, and Bluetooth 5.0 LE with a range of 10 m. Data can be exported in HL7 v2.5 or DICOM SR format, and the internal flash stores up to 8 GB of raw waveforms, equivalent to approximately 14 hours of continuous multimodal recording at 1 kHz sampling.
Export Compliance and Certification
The equipment complies with IEC 60601‑1:2012+A1:2020 for medical electrical safety, ISO 13485:2016 for quality management, and bears the CE marking under the EU MDR 2017/745. For North American markets it meets FCC Part 15 Subpart B and UL 60601‑1. Export shipments are classified under HS code 9018.90 and are packed in double‑wall corrugated cartons with internal foam inserts, achieving a drop test height of 1.2 m per ISTA‑3A.
Customization Options for OEM Partners
| Option | Typical Values / Choices | Impact on Lead Time |
|---|---|---|
| Firmware | Custom alarm thresholds, language packs, proprietary data formats | +2 weeks |
| Enclosure | Laser‑etched logo, color anodizing (black, blue, gray), optional IP66 rating | +1 week |
| Sensor Suite | Add/remove specific biomarkers (e.g., creatinine, glucose), adjust measurement ranges | +3 weeks |
| Calibration | Factory traceable to NIST, user‑selectable intervals (30/90/180 days) | Standard |
Quality Control and Testing
Each unit undergoes a 100 % functional test covering signal‑to‑noise ratio (>60 dB for ECG), leakage current (<0.1 mA), and IP65 verification. Environmental stress testing includes thermal cycling (‑20 °C to +70 °C, 20 cycles) and vibration (10‑500 Hz, 2 g rms) per MIL‑STD‑810G. Final audit checks traceability of components to supplier lot numbers and records calibration certificates.
Applications in Industrial Health Programs
Occupational health managers need real‑time monitoring of workers exposed to noise, heat, or chemical agents; the device’s rugged design allows deployment on shop floors, offshore platforms, or remote mining sites where traditional clinic equipment is impractical. Its low power consumption enables battery‑operated use for up to 12 hours, reducing reliance on mains power in temporary facilities.
Frequently Asked Questions
Can the measurement ranges be customized for specific OEM requirements?
Yes. Firmware parameters such as alarm thresholds, sampling rates, and biomarker calibration curves can be adjusted during the NRE phase. Mechanical changes like alternative sensor suites or enclosure IP ratings are also feasible, with lead times indicated in the customization table.
What information is needed to generate a quotation?
To prepare a quote we require the desired sensor configuration, enclosure customization details (logo, color, IP rating), expected annual volume, and any required certifications beyond the standard CE/FCC/UL. Providing a target price range helps us prioritize options.
Which materials are available for the enclosure?
Standard is 6063‑T5 aluminum alloy with a polycarbonate overlay. Optional upgrades include stainless‑steel 316L for corrosive environments, or a reinforced ABS‑PC blend for reduced weight. All options meet medical‑grade biocompatibility where applicable.
How is quality inspected before shipment?
Each lot receives a visual inspection, dimensional check (critical features ±0.1 mm), electrical safety test, and functional verification of all modalities. A random 10 % sample undergoes accelerated life testing (85 °C/85 % RH for 500 h) to confirm long‑term reliability.
What packaging methods protect the equipment during export?
Units are placed in anti‑static bags, then inserted into double‑wall corrugated cartons with 20 mm EPS foam inserts on all sides. Cartons are sealed with pressure‑sensitive tape and marked with handling symbols (fragile, this side up). The packaged unit passes ISTA‑3A drop and vibration tests.
Contact for Inquiry
To obtain a detailed technical datasheet, request a quotation, or discuss OEM customization, please contact our engineering team.
