Inquire NowOEM Body Composition Analysis System for Gym Testing
The system delivers segmental bioelectrical impedance analysis (BIA) with multi‑frequency excitation to estimate fat mass, lean mass, total body water, and visceral fat level. Measurements are completed in under 30 seconds per subject, supporting high‑throughput screening in fitness facilities.
Operating Principle
Four‑point electrodes placed on hands and feet inject a low‑amplitude alternating current (typically 5 kHz to 500 kHz) and measure the resulting voltage drop. Impedance values at each frequency are fed into a validated empirical model that separates intracellular and extracellular water compartments, enabling calculation of body composition compartments.
Key Technical Parameters
- Measurement range: 0 %–60 % body fat, 0 kg–300 kg total mass
- Frequency set: 5, 50, 100, 200, 500 kHz (user‑configurable)
- Repeatability (CV): ≤1.5 % for impedance, ≤2 % for derived fat mass
- Electrode contact resistance: <10 kΩ ensured by spring‑loaded sensors
- Power consumption: <15 W during measurement, <0.5 W standby
Typical Applications in Fitness Settings
Gyms use the system to establish baseline metrics for new members, track progress over training cycles, and tailor nutrition or exercise programs based on segmental lean mass distribution. The rapid throughput enables integration into member onboarding workflows without significant queue formation.
Customization Options for OEM Partners
Housing dimensions, electrode array layout, and firmware communication protocols can be adapted to match existing equipment enclosures or proprietary data management systems. Available interfaces include USB‑CDC, RS‑232, and Bluetooth LE with configurable data packets (JSON, CSV, or custom binary).
Quality Assurance Philosophy
Each unit undergoes a three‑stage verification: (1) electrical safety test per IEC 60601‑1, (2) impedance accuracy check against a precision resistor network, and (3) functional validation using a phantom with known tissue‑equivalent properties. Test results are recorded and traceable via serial number.
Model Comparison
| Parameter | Standard Model | High‑Capacity Model |
|---|---|---|
| Subject capacity per hour | 120 | 250 |
| Electrode material | Stainless steel 316 | Gold‑plated brass |
| Data storage (internal) | 8 GB flash | 32 GB flash |
| Operating temperature range | 5 °C–40 °C | 0 °C–45 °C |
Frequently Asked Questions
Yes, the hand and foot slides feature linear guides with detent positions at 5 mm intervals, accommodating users from 140 cm to 210 cm without tools.
What information is required before quotation?OEM partners should provide target housing dimensions, desired communication interface, expected annual volume, and any regulatory certifications needed for the destination market.
How are sample units arranged?Sample systems are shipped with a calibration certificate, user manual, and a set of disposable electrode gels. Lead time for samples is typically 3–4 weeks after receipt of technical specifications.
For detailed configuration discussions, pricing, or to request a formal proposal, please contact our engineering team.
