Budget Friendly Smart Body Fat Analyzer Scale

This device utilizes multi-frequency bioelectrical impedance analysis (BIA) to estimate body fat percentage, muscle mass, and water content.

Four stainless steel electrodes are placed on the platform surface to send and receive low‑level electrical signals.

Measurement is completed within 5 seconds after the user steps onto the scale.

Results are displayed on a 1.8‑inch LCD screen and can be transmitted via Bluetooth 5.0 to a companion app.

The scale’s hardware is housed in an ABS‑plastic chassis with a tempered glass top, providing resistance to scratches and moisture.

Power is supplied by two AA alkaline batteries, offering approximately 12 months of operation under typical usage of three measurements per day.

Typical Specifications

Values represent typical performance; actual results depend on user physiology, electrode contact, and environmental conditions.

Typical Applications

In corporate wellness programs, the scale provides quick, non‑invasive body composition data that can be integrated into health‑risk assessments.

Fitness centers use the device for member onboarding and progress tracking, where repeatability within ±0.5 % body fat supports reliable trend analysis.

OEM manufacturers incorporate the scale into connected health kiosks because its low power draw and Bluetooth module simplify system integration.

The compact footprint (300 mm × 300 mm × 25 mm) allows placement on limited‑space workstations or wall‑mounted brackets.

Selection Considerations

Electrode geometry influences current distribution; a four‑point rectangular layout reduces edge effects compared with circular designs.

Frequency selection affects tissue penetration; a range of 5 kHz to 200 kHz enables differentiation between intracellular and extracellular water.

Algorithm calibration requires validation against a reference method such as dual‑energy X‑ray absorptiometry (DXA) for the target population.

Environmental compensation for temperature and humidity is advisable when the scale operates in uncontrolled settings.

Quality and Reliability

Each unit undergoes factory calibration using precision resistors to verify impedance measurement accuracy within ±1 %.

Housing seals are rated IP‑X4, protecting against splashing water from any direction.

Firmware includes a self‑test routine that runs at power‑on, checking electrode continuity and battery voltage.

The electronics are designed for a typical MTBF of 30,000–50,000 hours under normal operating conditions.

Frequently Asked Questions

• Can the electrode spacing be customized? – Yes, the platform geometry can be adjusted to accommodate different foot sizes or specific ergonomic requirements.
• What information is needed for a quotation? – Required details include desired measurement parameters, expected annual volume, any required certifications, and preferred packaging.
• Is firmware upgradable in the field? – Firmware updates can be delivered via Bluetooth using a secure OTA procedure.
• How are export shipments protected? – Units are packed in double‑wall corrugated cartons with internal foam inserts and desiccant packs to mitigate shock and moisture.

Contact for Evaluation

To discuss technical suitability, request a sample unit, or obtain a detailed quotation, please reach out using the link below.
