B2B Digital Body Composition Analyzer

This device provides segmental bio‑impedance analysis for fat mass, lean mass, total body water and visceral fat rating with a measurement cycle under 30 seconds.

How the Analyzer Works

Eight tactile electrodes deliver a low‑amplitude alternating current at multiple frequencies (5 kHz, 50 kHz, 250 kHz). Impedance vectors are captured for each segment (arms, legs, trunk) and processed using patented multi‑frequency algorithms to derive compartment volumes.

Key Technical Specifications

Parameter	Typical Value
Measurement Frequencies	5 kHz, 50 kHz, 250 kHz
Electrode Count	8 (4 pair, hand‑to‑foot)
Segmental Output	Arms, legs, trunk (separate)
Measurement Time	≤ 30 s
Display	3.5‑inch LCD, 320×240 px
Data Interface	USB‑C, Bluetooth 5.0, optional Wi‑Fi
Power Supply	Li‑ion 3.7 V 2000 mAh, USB‑C charging
Operating Temp.	10 °C – 40 °C
Dimensions (W×H×D)	280 mm × 110 mm × 45 mm
Weight	1.2 kg

Primary Applications

Fitness centers use the analyzer to track member progress and adjust training programs based on segmental fat distribution.

Corporate wellness programs deploy the device for periodic health screenings, providing objective data that supports risk‑assessment models.

Medical research labs rely on the multi‑frequency segmental output to study fluid shifts in edema or dialysis patients without invasive procedures.

Measurement Accuracy & Calibration

Body fat percentage is validated against DXA with a typical error of ± 1.8 % for adults aged 18‑65.

Lean mass tracking shows a repeatability coefficient of variation below 1.2 % when measured under standardized hydration conditions.

Factory calibration uses a four‑compartment phantom with known resistivity; each unit receives a calibration certificate traceable to national standards.

Data Integration & Connectivity

The USB‑C port exports raw impedance data in CSV format compatible with MATLAB, Python pandas, and common BI tools.

Bluetooth 5.0 enables real‑time streaming to Android/iOS apps via GATT profile; data packets are encrypted with AES‑128.

Optional Wi‑Fi module allows direct upload to hospital HL7‑compliant servers using FHIR resources for body composition observations.

Build Quality & Materials

The housing is ABS‑PC blend with UL‑94 V‑0 flame rating, providing impact resistance up to 1 J and resistance to common cleaning agents.

Electrodes use stainless‑steel 316L contacts coated with medical‑grade silver‑silver chloride for stable impedance and low polarization.

Internal PCB conformal coating protects against humidity up to 85 % RH, ensuring reliable operation in tropical climates.

Customization Options

• Alternative electrode layouts (hand‑hand, foot‑foot) for specialized research protocols.
• Firmware tweaks to adjust output metrics (e.g., basal metabolic rate, segmental phase angle).
• Enclosure color matching corporate branding (Pantone‑matched).
• Extended battery pack for up to 8 hours continuous operation.

Quality Assurance & Testing

Each unit undergoes a 48‑hour burn‑in cycle at 40 °C to accelerate early‑life failures.

Final inspection includes impedance linearity test (± 0.5 % across 0‑1000 Ω range) and electrode contact resistance check (< 10 kΩ).

Statistical process control monitors key dimensions; Cp ≥ 1.33 is required for electrode spacing.

Lead Time & Support

Standard production lead time is 4‑6 weeks after receipt of approved drawings and payment terms.

Technical support provides SDK access, firmware updates, and on‑site calibration assistance upon request.

Spare parts (electrode cables, battery modules) are stocked for 2‑year warranty coverage.

Frequently Asked Questions

• Can the electrode spacing be adjusted for pediatric use? Yes, custom spacers are available for limb lengths down to 15 cm.
• What file formats are supported for data export? CSV, JSON, and XML; custom formats can be generated via the SDK.
• Is the device compliant with IEC 60601‑1? The analyzer meets IEC 60601‑1‑2 for electromagnetic compatibility and IEC 60601‑1 for basic safety.
• How often is recalibration recommended? Every 12 months or after 5000 measurement cycles, whichever comes first.
• Can the unit be integrated into existing gym management software? Yes, through the provided REST API or MQTT broker.

Ready to discuss how this analyzer can fit your facility’s workflow? Contact our technical team for a quotation and sample evaluation.
